Saniflo Sanitop UP 6002 Macerator Pump
The Saniflo Sanitop UP 6002 is a compact domestic macerator designed for use with a WC and wash basin where conventional gravity drainage may be difficult to achieve.
With 2 inlets, a 400 W motor, compact discharge pipe options and up to 5 metres recommended vertical lift, the Sanitop UP is a practical solution for an additional toilet, cloakroom or WC with basin.
Macerator for a Toilet & Wash Basin
The Sanitop UP is designed specifically for installations where a toilet and wash basin need to be installed away from a conventional soil stack or gravity waste connection.
Its compact two-inlet configuration makes it particularly suitable for cloakrooms, additional WCs, en-suite toilet areas and conversions where only a toilet and basin need to be connected.
Toilet
Wash Basin
2-appliance solution:
The Sanitop UP is designed for a WC and wash basin. If your installation also requires a shower or additional bathroom fixtures, a different Saniflo model may be more appropriate.
Saniflo Sanitop UP 6002 Features
✓ Designed for WC & Wash Basin
The Sanitop UP has two inlets and is designed to handle wastewater from a horizontal-outlet toilet and wash basin.
✓ Top Maintenance Access
Access from the top of the unit helps make inspection, servicing and maintenance easier.
✓ Direct Basket Access
The internal basket can be accessed in the event of certain blockages caused by improper use without dismantling the complete appliance or first emptying the tank.
✓ Single-Blade Cutting System
The Sanitop UP uses a single-blade cutter as part of its macerating system.
✓ Replacement-Friendly Design
Saniflo specifies identical pipe centres to help make replacement of an older model easier.
✓ Activated Carbon Filter
An activated carbon filter is included to help neutralise odours from the macerator unit.
Saniflo Sanitop 6002 Technical Specifications
Key specifications for the Saniflo Sanitop UP product code 6002.
*Maximum horizontal pumping distance depends on vertical lift, pipe layout, pipe diameter and bends.
How Far Can the Sanitop UP 6002 Pump?
The Sanitop UP has a recommended maximum vertical pumping height of 5 metres. Under suitable installation conditions, manufacturer information indicates horizontal pumping distances of up to approximately 100 metres at minimal vertical lift.
As the vertical lift increases, the available horizontal pumping distance reduces.
Planning the discharge pipe?
The combination of vertical lift, horizontal distance, pipe diameter and bends affects pumping performance. Follow the manufacturer’s installation instructions when planning the pipe run.
What’s Included With the Sanitop UP?
- Saniflo Sanitop UP macerator unit
- Non-return valve
- Connection fittings
- Activated carbon filter to help neutralise odours
Optional Saniflo Accessories
Product Code: 1095
EAN: 3308810042799
Product Code: 1085
EAN: 3308819899011
Sanitop UP 6002 Installation Information
Correct installation is important for reliable performance and low operating noise. The unit should remain accessible for inspection and maintenance and should be installed in the same room as the WC and wash basin connected to it.
Where should the Sanitop UP be installed?
How can operating noise be reduced?
What electrical connection is required?
Which discharge pipe sizes can be used?
Easy Maintenance Access
The Saniflo Sanitop UP 6002 features maintenance access from the top of the unit.
Saniflo also provides direct access to the internal basket so certain blockages caused by improper use can be reached without dismantling the entire appliance or emptying the tank first.
Regular cleaning and appropriate descaling can help keep the internal macerating components working correctly.
EN 12050-3 Sanitop Macerator
The Sanitop UP is identified as a K70 lifting plant for wastewater containing faecal matter and is declared in accordance with EN 12050-3.
The manufacturer’s Declaration of Performance records conformity for watertightness, airtightness, lifting effectiveness, mechanical resistance and durability.
Brand: Saniflo
Model: Sanitop UP
MPN: 6002
EAN: 3308815074061
EN 12050-3
Saniflo Sanitop 6002 Frequently Asked Questions
What is the Saniflo Sanitop UP 6002 used for?
How many appliances can connect to the Sanitop UP?
Can the Sanitop UP connect to a shower?
How high can the Sanitop UP pump?
How far horizontally can the Sanitop 6002 pump?
What size discharge pipe does the Sanitop UP use?
How noisy is the Saniflo Sanitop UP?
What is the Saniflo Sanitop 6002 barcode?
Can the Sanitop UP replace an older Sanitop?
Genuine Saniflo Sanitop UP – Product Code 6002
If you are searching for a Saniflo Sanitop 6002, Sanitop UP 6002, Saniflo 6002 macerator or a genuine Saniflo toilet and basin macerator, the Sanitop UP combines two appliance connections, a 400 W motor, compact discharge pipework, top maintenance access and up to 5 metres of recommended vertical pumping capability.
